Self propelled Aerial Working Lifitng Platform

Self propelled Aerial Working Lifitng Platform

    Unit Price: 8000 USD
    Min. Order: 1 Set/Sets
    Packaging: nude
    Productivity: 500units/month
    Transportation: Ocean,Land,Air
    Place of Origin: china
    Supply Ability: 500units/month
    Certificate: iso
    Port: Qingdao,Shanghai,Tianjin

Basic Info

Model No.: 001

Product Description

Articulating Aerial Working Platform


Articulating Aerial Working Platform
型号 Model Z-45 Z-52 Z-60 Z-66
承载能力 Lift capacity (kg) 230 230 230 230
可容纳人数 Max.platform occupancy 2 2 2 2
工作高度 Working height (m) 16.2 17.7 19.7 21.22
平台高度 Platform height (m) 14.2 15.8 18 19.52
最大水平延伸 Max.horizontal extension (m) 8 9.5 10.8 12.7
平台尺寸(长*宽*高) Platform size (L*W*H) (m) 1.83*0.76*1.13 1.83*0.76*1.13 1.83*0.76*1.13 1.83*0.76*1.13
总高 Overall height (m) 2.38 2.38 2.48 2.48
总长 Overall length (m) 6.2 6.8 8.25 9.23
总宽 Overall width (m) 2.29 2.29 2.38 2.38
轴距 Wheelbase (m) 2.2 2.2 2.6 2.6
最小离地间隙 Min.Ground Clearance (m) 0.43 0.43 0.43 0.43
旋转转台 Turnable rotation (°) 360 non-continuously 360 continuously 360 continuously 360 continuously
平台旋转 Platform rotation (°) 160 160 160 160
行驶速度(收起状态) Drive speed (platform lowered) (km/h) 6.3 6.3 6.3 6.3
行驶速度(起升状态) Drive speed (platform elevated) (km/h) 1.1 1.1 1.1 1.1
转向半径-内 Min.turning radius-inside (m) 3 3 3 3
转向半径-外 Min.turning radius-outside (m) 5.2 5.2 5.2 5.2
爬坡能力 Gradeability (%) 45 40 30 30
轮胎 Tire 33*12-20 33*12-20 33*12-20 33*12-20
发动机 Engine Cummins/perkins Cummins/perkins Cummins/perkins Cummins/perkins
辅助动力 Auxiliary power 12 V DC 12 V DC 12 V DC 12 V DC
液压油箱容量 Hydraulic tank (L) 90 90 90 90
燃油邮箱容量 Fuel tank (L) 100 100 100 100
重量 Weight (kg) 7577 7657 7750 8617
Standard Proportional control Options Hydraulic generator
Manual emergency pump Hydraulic welding machiner
Hour meter
Tilt protection system Solid non-marking tires
Turnable rotation 360° continuous
Auto leveling platform Hydraulic air compressor
Engine re-start protection
Engine glow plug preheating unit Hydraulic high pressure water pump
Foot switch
Oscillating axle chassis 4*4 drive
4*2 drive
Solid tire AC power to platform
Euro III emission standard engine
Fault diagnosis system Platform working light
Buzzer
Horn Overload sensor
Strobe light
Hydraulic oil radiator
